fin seal vertical packaging machine
Introduction
For the collar type pouch packing machine(FB-DF-420),it is a kind of vertical form fill and seal machines which specialized for the packaging of all kind of 150gram-1000gram granule/powder and vertical form filling and sealing into the fin seal pouches style.
Technical Parameters
Packaging material |
oatmeal,soy milk powder,puffed food,popcorn,seeds,tea leaf etc |
|
Available filling capacity |
150g-1000g |
|
vffs bags style |
fin seal pouches |
|
Finished pouch size(min to max) |
Length: |
50mm-300mm |
width: |
80mm-200mm |
|
vertical form filling and sealing speed(sachet/min) |
15-60 |
|
Material of machinery |
SUS304 |
|
Material contact parts |
SUS316 |
|
Additional components of machine |
screw style feeder |
|
turntable feeder |
||
multi-head electronic scale |
||
Power supply |
AC 380V /50Hz (customized based on different voltages) |
|
Total power |
4KW |
|
Machine weight |
650KG |
|
Machine dimension |
1400mm*970mm*1600mm |
|
youtube vertical form fill and seal |
working process
film rolling->forming->filling->sealing->finishing
pneumatic components
